Brass Push In Air Brake Male Connector Fitting
- Quick Disconnect - Simply Push Tubing In, No Tools Or Loose Parts To Handle In Tight Places.
- Full Flow Design, Provides Up To 60% More Flow Area Than Conventional Fittings With Internal Tube Supports.
- Brass Construction.
- Pre-Applied PTFE Based Pipe Sealant On All Male Pipe Threads.
- Typical Applications: Air Operated Seats, Windows, Door Locks, Mirrors, Wipers, Gauges, Air Horns, Heater Controls, Gear Shifts, Fifth Wheels, And Air Brake Connections.
- Working Pressure: 250 Psi
- Temperature Range: -20° F. To 200° F.
- Tube Outside Diameter: 1/8
- Male Pipe Thread: 1/16
- Applications: Sae J844 Type A And B.
Meets Standards
D.O.T. FMVSS 571.106 and SAE J1131
Brass DOT Push-to-Connect Fittings Type
Connectors
Connection Type
Male
Pipe Thread
1/16 in.
Shape
Connector
Fitting Style
Push-To-Connect
Shipping Weight
0.1 lb.
Fitting Type
Push-To-Connect
System of Measurement
Fractional
Gasket Material
Ethylene Propylene
Tube Outside Diameter
1/8 in.
Grade
CA360
Vibration Resistance
Moderate
Hex Size
3/8 in.
Working Pressure
Determined by maximum working pressure of the recommended plastic tubing
Material
Brass
