Newstar

Inside Snap Ring Style End Yoke - 1000 Series

$17.36
No reviews yet Write a Review
Adding to cart… The item has been added
SKU:
S-8630
UPC:
643553377979
  • Free Ground Shipping

  • Free Returns and Exchanges

  • Amazing Selection

Inside Snap Ring Style End Yoke

1000 Series

1" Bore Diameter



Bore Diameter:1 Inch
C/l To End Of Hub:2.5
Centerline to End:2.5 Inch
Hole Diameter:0.375 Inch
Hub Diameter:2 Inch
Joint Angle:60 Degrees
Keyway Width:0.25 Inch
Length Thru Hole:1.03 Inch
Length Thru Hole:1.03 Inch
Location Of Keyway:3
Location Of Set Screw:9
Material:Steel
Maximum Hub Diameter:1.625 Inch
Round Hole Diameter:1 Inch
Sae Keyway Width:0.25 Inch
SAE Keyway Width:0.25 Inch
Series:1000 Series
Style:ISR
Yoke Bearing Dimension:0.938 Inch
